FEATURES
An earth resistance tester is used to measure grounding resistance for grounding pole connected to some conductive part of facility in the power distribution unit of power circuit or building structure, for working grounding, for safeguard grounding. The tester used for the furnish power, transformer station, power distribution lines, in-house wiring system, electrical appliances etc.
SPECIFICATIONS
suring Range
2Ω : 0.5 ~ 1.999Ω
20Ω : 2 ~ 19.99Ω
200Ω : 20 ~ 199.9Ω
Accuracy
±2% rdg±0.02Ω (2Ω)
±2% rdg±0.1Ω (20Ω)
±2% rdg±3 rdg (200Ω)
Voltage
0 ~ 200V
Resolution
0.001Ω / 0.01Ω / 0.1Ω
Over Load Protection
√
Auto Power Off
Safety Standard
IEC 61010-1 Overvoltage CAT III 300V Pollution Degree 2
IEC 61010-2-31 / IEC 61557-1,5 / IEC 60529 (IP54)
External power supply
9V DC
PACKING INFORMATION
Power
6*1.5V AA battery
Product Net Weight
533g
Product Size
174*122*65mm
Packing
Backpack
Standard Quantity Per Carton
6
Standard Carton Size
45*32*55cm
Standard Carton Gross Weight
15.23KG
